Features

Specs

• 2-speed Hoist w/ Grooved Drum, Roller Tensioner, Piston Motor
• 4 or 5 Section Telescopic Boom
• 4-Load Sheave Quick Reeve Boom Head
• Hard Wired Anti-Two Block w/ Lockout
• Boom Hoist Cylinder
• System Pressure Gauge
• 360° Area of Operation
• Continuous Rotation
• Tilting Cab w/Heater & Windshield Cover & Upper Cab Guard
• Removable Boom Rest
• Engine Start/Stop
• Combined Free Swing and Non-Free Swing Functionality
• Hydraulic Rotation Drum Indicator
• Electronic Throttle
• 3-Section, Vane Pump-Counter Clockwise - Std.
• Operator's Service/Parts Manuals
• Boom Length and Angle Indicators
• 5 Ton (4.5 mt) Hook and Ball
• 400' (122m) or 500' (152m), 5/8" (16mm) Dia. Rotation Resistant Wire Rope
• Audible Outrigger Motion Alarm
• 115 Gal (435 L) or 150 Gal (568 L) Hyd Reservoir w/Suction Strainer & Ball Valve
• Turret, Rotation Bearing & Swing System -Mechanical Houselock
• New Load Moment Indicator - Full Visual/Audio Capacity Alert w/Shutoff
• ROCSolid outriggers; 4 Out-And-down outriggers, 22' (6.71m) over-all spread. Features a Hand Held Radio Operated Controller and includes capacities for Intermediate 13'4" (4.05m) and Retracted 7'2" (2.18m) Spreads.
• Remote Winch Controls included with the Hand Held Radio Controller for the outriggers
• Outrigger Monitoring System -Verification Only
• Front Bumper Stabilizer - for Short lower frame configurations
• 2 Retractable Ladders for Easy Access to Deck
• Diamond Plated Aluminum Decking
• Aluminum Step Ladder - Deck mounted, multi-position Oil Cooler
• Bubble Level
• Signal Horn
